Sildītājs 75W, 160x50x80 mm, 120-240/50-60
Artikuls STHT75T
82,95 €
Pārdošanā
Saglabāt šo produktu vēlākam
Klientu atsauksmes
Atsauksmes tikai no verificētiem klientiem
Pagaidām nav atsauksmju. Jūs varat iegādāties šo produktu un būt atstāt par to pirmo atsauksmi.
Dalīties ar šo preci savu draugu vidū
Sildītājs 75W, 160x50x80 mm, 120-240/50-60
Preces apraksts
UPC: STHT75T
Brand: Alfa electric
| Features | 63x70X140 mm | |
| Description | Heater PTC 75 W terminals; integrated thermostat, CE | |
| Heating Capacity [W] |
75 | |
| Power supply [V/Hz] |
120-240/50-60 | |
| Delayed fuse (advised) [A] |
6.3 | |
| Heating Capacity* | W | 75 |
| Power supply | V | 110-250V AC or DC |
| Inrush current | A | 4 |
| Delayed fuse (advised) | A | 6.3 |
| Heating element type | - | PTC resistor, self-regulation |
| Electrical connections | - | 2 screw terminals for stranded or rigid wire 2.5 mm² |
| Protection class | - | Class II |
| Protection degree EN60529 | - | IP20 |
| Operating temperature | °C (°F) | -45/+70 (-49/+158) |
| Storage temperature | °C (°F) | 45 / +80 (-49 / +176) |
| Radiator | - | Extruded aluminium profile, anodized |
| Mounting | - | Clip for mounting on DIN rail 35 mm EN50022 |
| Installation position | - | Best efficiency in vertical position |
| Dimensions HxWxD | mm | 160x50x80 |
| Weight (with packaging) | kg | 0.43 (0.47) |
| Conformity/Certification | - | CE |
| *at 20°C (68°F) ambient temperature | ||
| Accessories | ||
| Thermostat NC 0-60°C | THR2 | |
| Double thermostat NC 0-60°C NO 0-60° | THRV22 | |
| Hygrothermostat 0-60°C 20-90%RH | ETUH22 | |
| Hygrostat 10-90%RH | MUH |
